Technical Specifications

Crew

2/8

Passengers

381 economic

Propulsion

2 Turbofan Engines

Engine Model

General Electric GE90-94B

Engine Power (each)

432,8 kN

97300 lbf

Speed

950 km/h

513 kts
590 mph

Mmo (max. Mach)

Mach 0.84

Service Ceiling

13.137 m

42.000 ft

Range

9.695 km

5.235 NM
6.024 mi.

Empty Weight

134.800 kg

297.250 lbs

max. Takeoff Weight

242.672 kg

535.000 lbs

max. Landing Weight

201.800 kg

445.000 lbs

Wing Span

60,93 m

199 ft 11 in

Wing Area

427,8 m²

4605 ft²

Length

63,73 m

209 ft 1 in

Height

18,51 m

60 ft 9 in

Production Status

in production

Production Range

1994-2022

Boeing
777-2

HISTORY

The Boeing 777, commonly referred to as the Triple Seven, is an American long-range wide-body airliner developed and manufactured by Boeing Commercial Airplanes. It is the world’s largest twin-jet. The 777 was designed to bridge the gap between Boeing’s other wide body airplanes, the twin-engined 767 and quad-engined 747, and to replace older DC-10s and L-1011 tri-jets. Developed in consultation with eight major airlines, with a first meeting in January 1990, the program was launched in October, with an order from United Airlines. The prototype was rolled out in April 1994, and first flew in June. The 777 entered service with the launch customer, United Airlines, in June 1995. Longer range variants were launched in 2000, and were first delivered in 2004.

It can accommodate a ten–abreast seating layout and has a typical 3-class capacity of 301 to 368 passengers, with a range of 5,240 to 8,555 nautical miles (9,700 to 15,840 km). It is recognizable for its large-diameter turbofan engines, six wheels on each main landing gear, fully circular fuselage cross-section, and a blade-shaped tail cone. It is the first Boeing aircraft with fly-by-wire controls. It initially competed with the Airbus A340 and the McDonnell Douglas MD-11, both now out of production, and as of 2021 competes with the Airbus A350 and A330-900.

The original 777 with a maximum takeoff weight (MTOW) of 545,000–660,000 lb (247–299 t) was produced in two fuselage lengths: the initial -200 was followed by the extended-range 777-200ER in 1997; and the 33.25 ft (10.13 m) longer 777-300 in 1998. Those 777 Classics were powered by 77,200–98,000 lbf (343–436 kN) General Electric GE90, Pratt & Whitney PW4000, or Rolls-Royce Trent 800 engines. The longer-range 777-300ER, with a MTOW of 700,000–775,000 lb (318–352 t), entered service in 2004, the ultra long-range 777-200LR in 2006, and the 777F freighter in 2009. These long haul variants use 110,000–115,300 lbf (489–513 kN) GE90 engines and have extended raked wingtips. In November 2013, Boeing announced the 777X development with the -8 and -9 variants, both featuring composite wings with folding wingtips and General Electric GE9X engines.

The 777 has been ordered and delivered more than any other wide-body airliner; as of September 2022, more than 60 customers had placed orders for 2,136 aircraft of all variants, with 1,695 delivered. The most common and successful variant is the 777-300ER with 838 aircraft ordered and 832 delivered. By March 2018, the 777 had become the most produced Boeing wide-body jet, overtaking the Boeing 747. As of 2018, Emirates was the largest operator, with 163 aircraft. As of September 2021, the 777 had been involved in 31 aviation accidents and incidents, including 8 hull losses (5 during flight and 3 on the ground) with 541 fatalities, and 3 hijackings.

Technical Specifications

Crew

2/8

Passengers

381 economic

Propulsion

2 Turbofan Engines

Engine Model

General Electric GE90-94B

Engine Power (each)

432,8 kN

97300 lbf

Speed

950 km/h

513 kts
590 mph

Mmo (max. Mach)

Mach 0.84

Service Ceiling

13.137 m

42.000 ft

Range

9.695 km

5.235 NM
6.024 mi.

Empty Weight

134.800 kg

297.250 lbs

max. Takeoff Weight

242.672 kg

535.000 lbs

max. Landing Weight

201.800 kg

445.000 lbs

Wing Span

60,93 m

199 ft 11 in

Wing Area

427,8 m²

4605 ft²

Length

63,73 m

209 ft 1 in

Height

18,51 m

60 ft 9 in

Production Status

in production

Production Range

1994-2022
